About the Printer | 21
Rear View
*1
USB 3.0 device port
*2
USB 2.0 host port (for Smart Card)
1 Control Board 8 Ethernet Port
2 Left Side Cover 9 Power Inlet
3 "Blue" Plug 10 Duplex Unit
4 Phone Connector
• Do not connect any device (fax
system) other than a telephone or
a telephone answering device.
11 2nd Belt Transfer Roller (2nd BTR)
5 Wall Jack Connector 12 Fusing Unit
6 Wireless Adapter Socket 13 Rear Cover
7USB Port
*1
14 USB Port
*2
12
3
4
5
6
7
8
9
11
12
13
10
14
