Loading Print Media | 211
5 When you load Legal-size paper, extend the tray while pushing the lever located on
the front part of the tray.
6 Before loading the print media, flex the sheets and fan them. Straighten the edges of
the stack on a level surface.
7 Load the print media into the tray with the recommended print side facing up.
• Do not exceed the maximum fill line in the tray. Overfilling the tray may cause paper jams.
• When loading coated paper, load one sheet at a time.
8 Align the width guides against the edges of the paper.
• Overtightening the guides may cause jams.
• When loading user-specified print media, adjust the width guides and slide the extendable part
of the tray by pinching the length guide and sliding it until it rests lightly against the edge of the
paper.
9 Reinstall the security cover as necessary.
