Delta Electronics ASDA-B2 series User Manual

ASDA-B2 Chapter 3 Connections and Wiring
Revision September 2013 3-25
SPD1
PT-S, S-T
8
SPD1 SPD0 Parameter
OFF OFF
S mode: analog input
Sz mode: 0
OFF ON P1-09
ON OFF P1-10
ON ON P1-11
TCM0
PT, T, Tz,
PT-T
34
Select the source of torque command:
TCM1 TCM0 Parameter
OFF OFF
T mode: analog
input
Tz mode: 0
OFF ON P1-12
ON OFF P1-13
ON ON P1-14
TCM1 S-T 8
S-P PT-S 31
Speed / Position mode switching
OFF: Speed, ON: Position
S-T S-T 31
Speed / Torque mode switching
OFF: Speed, ON: Torque
T-P PT-T 31
Torque / Position mode switching
OFF: Torque, ON: Position
EMGS ALL 30
It should be contact “b” and normally ON or a
fault (ALRM) will display.
NL(CWL)
PT, S, T
Sz, Tz
32
Reverse inhibit limit. It should be contact “b”
and normally ON or a fault (ALRM) will
display.
PL(CCWL)
PT, S, T
Sz, Tz
31
Forward inhibit limit. It should be contact “b”
and normally ON or a fault (ALRM) will
display.
TLLM
Not
assigned
-
Reverse operation torque limit (Torque limit
function is valid only when P1-02 is enabled)
TRLM
Not
assigned
-
Forward operation torque limit (Torque limit
function is valid only when P1-02 is enabled)
JOGU ALL -
Forward JOG input. When JOGU is activated,
the motor will JOG in forward direction.
JOGD ALL -
Reverse JOG input. When JOGD is activated,
the motor will JOG in reverse direction.
GNUM0 PT, PT-S -
Electronic gear ratio (Numerator) selection 0
[See P2-60~P2-62]
GNUM1 PT, PT-S -
Electronic gear ratio (Numerator) selection 1
[See P2-60~P2-62]
