Delta M100A 283

The components is shown as Figure 2-1.
2.2 Product Overview
Figure 2-1: Components
①
⑤
③② ④
⑥ ⑦
Table 2-1: Packing list
M100A_280 / M100A_283 / M110A_283
Object Qty Description
1 Delta Solar Inverter 1 pc
1 pc
Solar inverter
H4 Wrench 2 pcs To disconnect H4 connector
6
Protective Frame 6 pcs Protect DC connectors
7
Security Seal 3 pcs Tamper stickers for Taiwan use only
8
H4 Connector 16 pairs DC string inputs
2
1 pc3
User Manual
Important instructions for solar inverter.
Safety instructions should be followed
during installation and maintenance.
Mounting Bracket
Wall mounting bracket
(Material: Aluminum/Thickness: 3mm)
Keep the door being open.
Can unscrew the latch lock cover screw.
5
1 pc
(Installed on latch lock cover)
Hexagon Driver
4
⑧
13
Introduction
