Protection cover
CAUTION !
To avoid malfunction of inverter caused by extreme
weather (ex: snow, hail…etc) or non-proper installation/
maintenance, an additional protection cover is strongly
recommended to be installed by DELTA.
For more details, please contact local service team.
The inverter can only be carried out vertically, the tilting must be in the range of
the maximum inclination as Figure 3-3.
3.2 Mechanical Installation
Figure 3-3: Permitted mounting positions
allowable tolerance scope
WARNING !
- Do not install the unit near or on flammable surfaces.
- Inverter must be mounted securely to a solid / smooth surface.
90
<30
±1
19
Installation
