NO 位置 螺絲扭力
2 內部風扇組件 2
6.0 kgf-cm (0.6N•m)
1 內部風扇架 2
8.0 kgf-cm (0.8N•m)
3 內部風扇架 1
4 內部風扇組件 1
8.0 kgf-cm (0.8N•m)
6.0 kgf-cm (0.6N•m)
附錄-2: 組裝說明-2
① ② ③
④
附錄
170
