Periodic fan and filter cleaning is required to insure long life and reliability.
- The time period between cleanings depends on the quality of the environment.
- Under normal duty use, Delta recommends smart fans and filters be cleaned
every 4 months
- For very dusty locations, it may be necessary to clean the fans and filters
quarterly or monthly.
ATTENTION
The cooling fans feature modular designs that make their removal for cleaning
or replacement a simple task. As a result, the replacement of fans is also smart.
The inverter has one fan tray for power module cooling and two internal fans for
inside air circulation as shown in Figure 5-10 to 5-17
• Power Module (PM) compartment
• Inside the inverter compartment
5.3 Smart Fans Replacement and Filter Cleaning
- Prior to beginning any maintenance procedures outside AC breaker and DC switch
off to avoid risk of electrical shock!
DANGER : ELECTRICAL HAZARD!!
65
Maintenance
