Delta M100A 283

圖 7-5: 環境溫度對應輸出能力降額曲線(380 Vac)
Output Power (kW)
Pn=100kW
Power De-rating Curves with PV Voltage
Output voltage at 380Vac
PF=1
500
200
300 400
600 700 800 900 1000
50
40
30
60
70
80
90
100
110
20
10
0
Input DC Voltage (V)
@ Ambient 25°C
@ Ambient 30°C
@ Ambient 40°C
@ Ambient 50°C
P/Pn(%)
Pn=100kW
Power Derating Curve with Ambient Temperature
Output voltage at 480 Vac
PF=1
Ambient Temperature (
°C )
20
0 10
30 40 6050
70 %
80 %
90 %
100%
110%
550V
610V
720V
840V
