Figure 3-2: Lift the inverter
Do not hold fan, fan shutter, AC gland, DC switches or DC
connector, it may cause damage to certain components.
Manual handling
Hoisting
After hoisting, please keep the screw plugs on
the casing to prevent water from entering.
Hoisting ring
(M12 x P1.75, L ≤ 20 mm)
(42 N-m)
Screw plug
(4 N-m)
18
Installation
