Figure 5-3: Remove the door
Figure 5-4: Close the door
security seal
① ②
③
④ ⑤
- This inverter is compliant with the “Technical Specification for Security Inspection
of Solar Inverter and Monitoring Units” required by BSMI. After closing the door,
please apply a security seal on the toggle latch. We will not be liable or responsible
for any security incident caused by an improper application of the sticker.
- After cabling or maintenance for the inverter, please properly lock both toggle
latches to make sure the inverter will remain IP66 protection.
ATTENTION
2 N-m torque
59
Maintenance
