Delta M100A 283

Figure 7-3: Power Derating Curve with Ambient Temperature (400 Vac)
P/Pn(%)
Pn=100kW
Power Derating Curve with Ambient Temperature
Output voltage at 400 Vac
PF=1
Ambient Temperature (
°C )
30
0
10 20
40 50 60
50 %
60 %
70 %
80 %
90 %
100%
110%
550V
610V
720V
840V
Figure 7-2: Power Derating Curve with Ambient Temperature (380 Vac)
P/Pn(%)
Pn=100kW
Power Derating Curve with Ambient Temperature
Output voltage at 380 Vac
PF=1
Ambient Temperature (
°C )
20
0 10
30 40 6050
50 %
60 %
70 %
80 %
90 %
100%
110%
550V
590V
720V
840V
80
Technical Information
