Delta M100A 283

NO Location Screw torque Conductor cross-section
1 SPD board
8.0 kgf-cm (0.8N•m)
2 AC Cover
3 Toggle Latch
8.0 kgf-cm (0.8N•m)
25 kgf-cm (2.45N•m)
Communication port
-
4
-
-
-
5
AC
terminal
20 AWG (0.5mm²)
L1, L2, L3, N
PE
422 kgf-cm (42.4 N•m)
M8/ 150 kgf-cm (14.7 N•m)
M10/ 250 kgf-cm (24.5 N•m)
Cu: 70 mm
²
(3/0 AWG) ~ 240 mm
²
(470 kcmil)
Al: 120 mm²(4/0 AWG) ~ 240 mm²(470 kcmil)
Appendix-3: Assembly Note-3
③
①
④
④
②
②
⑥
③
⑤
①
④
+
12V
+
12V
--
⑤
