Seven
™
System User’s Guide | 123
TIMEELAPSED PLOTS
Examples of Seven Continuous Glucose Monitoring System overlaid with the
corresponding YSI readings over time are presented below. e horizontal axis represents
time, with the matching Seven System and YSI readings plotted above the point in time
when the measurements were taken. e circles (
) on the graph represent the Seven
System data, connected by a line. e “Y” represents the YSI reading.
ere are three Figures presented. Figure 2 is an example of when the Seven System
performed well, Figure 3 represents a period when the Seven System performed in an
average manner, and Figure 4 represents when the Seven System performed poorly.
