Diesse cube 30 touch - Page 47

Rev. 2.3
CUBE 30 TOUCH | USER MANUAL
47
"........... .." in the ID field, as seen for the sample in POS NUM 03, it indicates the lack of
the sample barcode
“S”, “M”, “P” after the sample barcode indicate that the analyzed sample is in a Sarstedt
S, BD Microtainer MAP or pediatric tube, respectively (samples 04, 05, 06, 07)
"ERR" displayed in the ESR value column indicates an error (see TROUBLESHOOTING),
see sample 10
"HIGH", "LOW" are error coding strings of respectively high sample (POS NUM 08) and
low sample (POS NUM 04)
“> 140” (POS NUM 09), is the string used to indicate ESR values greater than 140 (POS
NUM 13).
"!" after the ESR result it indicates that the sample was analyzed with a temperature
that does not respect the established limits. For details, see paragraph
9.1
If the samples are printed from the archive (see paragraph 5) the receipt contains the
following information:
• Date and time of the analysis of each sample
• Position of each sample
• Sample ID
• HCT value expressed as a percentage (optional)
• ESR result with the reference method
Figure 47 - Receipt from the archive
DIESSE
Diagnostica senese
CUBE 30 TOUCH - V 2.XX
SN 2021 – 06 – 1999
11/01/2022-11:45 POS.23
SAMPLE ID:
030047877………..
ESR RESULT: 5 mm/h [W]
__ __ __ __ __ __ __ __ __ __ __ __ __ __ __
11/01/2022-08:12 POS.1
SAMPLE ID:
11238688…………
ESR RESULT: 46 mm/h! [W]
__ __ __ __ __ __ __ __ __ __ __ __ __ __ __
12/12/2021-13:54 POS.7
SAMPLE ID:
0300441879……….
HCT: 25%
ESR RESULT: 11 mm/h! [W]
