Serial port Configure Remote Access mode
Digi Connect EZ Mini User Guide
111
n rs-422
l Enable Termination if you want to enable electrical termination on this serial port.
n rs-485
l Enable termination if you want to enable electrical termination on this serial port:
(config)> serial port1 termination true
(config)>
l Enable full_duplex if you want to enable full duplex communication on this serial
port:
(config)> serial port1 full_duplex true
(config)>
The default is rs-232.
7. (Optional) Set a label that will be used when referring to this port.
(config)>serial port1 label label
(config)>
8. Set the baud rate used by the device to which you want to connect:
(config)>serial port baudrate rate
(config)>
9. Set the number of data bits used by the device to which you want to connect:
(config)>serial port databits bits
(config)>
10. Set the type of parity used by the device to which you want to connect:
(config)>serial port parity parity
(config)>
Allowed values are:
n even
n odd
n none
The default is none.
11. Set the stop bits used by the device to which you want to connect:
(config)>serial port stopbits bits
(config)>
12. Set the type of flow control used by the device to which you want to connect:
(config)>serial port flow value
(config)>
