Frame descriptions Legacy RX Indicator frame - 0x80

XBee®-PRO 900HP/XSC RF Modules

135

Frame data fields Offset Example

Start delimiter 0 0x7E

Length MSB 1 0x00

LSB 2 0x11

Frame type 3 0x80

64-bit source address MSB 4 0x00

5 0x13

6 0xA2

7 0x00

8 0x40

9 0x52

10 0xC5

LSB 11 0x07

RSSI 12 0x28

Options 13 0x01

Received data

14 0x52

15 0x78

16 0x44

17 0x61

18 0x74

19 0x61

Checksum 20 0xFF
