AT commands Addressing commands
XBee®-PRO 900HP/XSC RF Modules
86
Parameter range
0 - 0xFFFFFFFF
Default
0x0000FFFF
TO (Transmit Options)
The bitfield that configures the transmit options for Transparent mode.
Parameter range
0 - 0xFF
Bit field:
Bit Meaning Description
6,7 Delivery method
b’00 = <invalid option>
b’01 = Point-multipoint
b'10 = Directed Broadcast (0x80)
b’11 = DigiMesh (not available in the 10k product)
5 Reserved <set this bit to 0>
4 Reserved <set this bit to 0>
3 Trace route Enable a Trace Route on all DigiMesh API packets
2 NACK Enable a NACK messages on all DigiMesh API packets
1 Disable RD Disable Route Discovery on all DigiMesh unicasts
0 Disable ACK Disable acknowledgments on all unicasts
Example 1: Set TO to 0x80 to send all transmissions using repeater mode.
Example 2: Set TO to 0xC1 to send transmissions using DigiMesh, with network acknowledgments
disabled.
n Bits 6 and 7 cannot be set to DigiMesh on the 10k build.
n Bits 4 and 5 must be set to 0.
n Bits 1, 2, and 3 cannot be set on the 10k build.
Default
0x40 (10k product)
0xC0 (200k product)
NI (Node Identifier)
Stores the node identifier string for a device, which is a user-defined name or description of the
device. This can be up to 20 ASCII characters.
