Legacy S3B hardware certifications ISED (Innovation, Science and Economic Development Canada)
XBee®-PRO 900HP/XSC RF Modules 262
Antenna options: 900 MHz antenna listings
The antennas in the tables below have been approved for use with this module. Digi does not carry all of these antenna variants. Contact Digi Sales for
available antennas.
All antenna part numbers followed by an asterisk (*) are not available from Digi. Consult with an antenna manufacturer for an equivalent option.
Part number Type
Connector
Gain Application
Cable Loss or power reduction for S3B
device
Omni-directional antennas
A09-F0 Fiberglass Base Station RPN 0 dBi Fixed 0dB
A09-F1 Fiberglass Base Station RPN 1.0 dBi Fixed 0dB
A09-F2 Fiberglass Base Station RPN 2.1 dBi Fixed 0dB
A09-F3 Fiberglass Base Station RPN 3.1 dBi Fixed 0dB
A09-F4 Fiberglass Base Station RPN 4.1 dBi Fixed 0dB
A09-F5 Fiberglass Base Station RPN 5.1 dBi Fixed 0dB
A09-F6 Fiberglass Base Station RPN 6.1 dBi Fixed 0dB
A09-F7 Fiberglass Base Station RPN 7.1 dBi Fixed 0dB
A09-F8 Fiberglass Base Station RPN 8.1 dBi Fixed 0dB
A09-F9 Base Station RPSMAF 9.2 dBi Fixed 0dB
A09-W7 Wire Base Station RPN 7.1 dBi Fixed 0dB
A09-F0 Fiberglass Base Station RPSMA 0 dBi Fixed 0dB
A09-F1 Fiberglass Base Station RPSMA 1.0 dBi Fixed 0dB
A09-F2 Fiberglass Base Station RPSMA 2.1 dBi Fixed 0dB
