AT commands I/O settings commands

XBee®-PRO 900HP/XSC RF Modules

Parameter range

0 - 5

Parameter Description

0 Disabled

1 Commissioning Pushbutton

2 ADC

3 Digital input

4 Digital output, low

5 Digital output, high

Default

D1 (DIO1/AD1)

Sets or displays the DIO1/AD1 configuration (pin 19).

Parameter range

0 - 6

Parameter Description

0 Disabled

1 Commissioning button

SPI_ATTN

2 ADC

3 Digital input

4 Digital output, low

5 Digital output, high

6 UART Data Present Indicator

6 PTI_EN

Default

D2 (DIO2/AD2)

Sets or displays the DIO2/AD2 configuration (pin 18).
