AT commands I/O settings commands
XBee®-PRO 900HP/XSC RF Modules
94
Parameter Description
2 API Mode With Escapes. The device is in API mode and inserts escaped sequences to
allow for control characters. The device passes XON, XOFF, Escape, and the 0x7E
delimiter as data.
Default
0
AO (API Options)
The API data frame output format for RF packets received. This parameter applies to both the
UARTand SPI interfaces.
Use AO to enable different API output frames.
Parameter range
0, 1
Parameter Description
0 API Rx Indicator - 0x90, this is for standard data frames.
1 API Explicit Rx Indicator - 0x91, this is for Explicit Addressing data frames.
Default
0
I/O settings commands
The following AT commands are I/O settings commands.
CB (Commissioning Pushbutton)
Use CB to simulate commissioning pushbutton presses in software.
Set the parameter value to the number of button presses that you want to simulate. For example,
send CB1 to perform the action of pressing the Commissioning Pushbutton once.
See Commissioning pushbutton and associate LED.
See Commissioning pushbutton.
Parameter range
0 - 4
Default
N/A
D0 (DIO0/AD0)
Sets or displays the DIO0/AD0 configuration (pin 20).
