AT commands Serial interfacing commands

XBee®-PRO 900HP/XSC RF Modules

Value Description

0x1 2,400 b/s

0x2 4,800 b/s

0x3 9,600 b/s

0x4 19,200 b/s

0x5 38,400 b/s

0x6 57,600 b/s

0x7 115,200 b/s

0x8 230,400 b/s

Default

0x03 (9600 b/s)

NB (Parity)

Set or read the serial parity settings for UART communications.

Parameter range

0x00 - 0x02

Parameter Description

0x00 No parity

0x01 Even parity

0x02 Odd parity

Parameter Description

0 No parity

1 Even parity

2 Odd parity

Default

0x00

SB (Stop Bits)

Sets or displays the number of stop bits in the data packet.

Parameter range

0 - 1

Default Chapter4
