Digi XBee-PRO S3 User Manual

AT commands I/O settings commands
XBee®-PRO 900HP/XSC RF Modules
98
Parameter Description
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
Default
0
D7 (DIO7/CTS)
Sets or displays the DIO7/CTS configuration (pin 12).
Parameter range
0, 1, 3 - 7
Parameter Description
0 Disabled
1
CTSflow control
2 N/A
3 Digital input
4 Digital output, low
5 Digital output, high
6 RS-485 Tx enable, low Tx (0 V on transmit, high when idle)
7 RS-485 Tx enable high, high Tx (high on transmit, 0 V when idle)
Default
0x1
D8 (DIO8/SLEEP_REQUEST)
Sets or displays the DIO8/SLEEP_REQUEST configuration (pin 9).
The XBee-PRO 900HP RF Module does not support sleep. The SLEEP_REQUEST option is provided for
compatibility purposes and does not affect the device.
Parameter range
0, 1, 3 - 5
