Technical specifications General specifications
XBee®-PRO 900HP/XSC RF Modules
17
General specifications
The following table describes the general specifications for the devices.
Specification Value
Operating frequency band
1
902 to 928 MHz (software selectable channels)
Dimensions 3.29 cm x 2.44 cm x 0.546 cm (1.297" x 0.962" x 0.215)
Dimensions do not include connector/antenna or pin lengths
Weight 5 to 8 grams, depending on the antenna option
Operating temperature -40 ºC to 85 º C (industrial)
Antenna options Integrated wire, U. FL RF connector, reverse-polarity SMA
connector
Digital I/O Fifteen (15) I/O lines,
Analog-to-digital converter
(ADC)
Four (4)10-bit analog inputs
Networking specifications
The following table provides the networking specifications for the device.
Specification Value
Supported network topologies Mesh, point-to-point, point-to-multipoint, peer-to-peer
Number of channels, user selectable
channels
64 channels available
Addressing options Personal Area Network identifier (PAN ID), Preamble ID, and
64-bit addresses
Encryption 128 bit Advanced Encryption Standard (AES)
Regulatory conformity summary
This table describes the agency approvals for the devices.
Country Approval
United States (FCC Part 15.247) MCQ-XB900HP
Innovation, Science and Economic Development Canada
(ISED)
1846A-XB900HP
1
Supply voltages of less than 3.0 V may reduce performance. Output power and receiver sensitivity may
degrade.
