XBee-PRO XSC specifications Performance specifications
XBee®-PRO 900HP/XSC RF Modules
188
Performance specifications
The following table describes the performance specifications for the devices.
Note Range figure estimates are based on free-air terrain with limited sources of interference. Actual
range will vary based on transmitting power, orientation of transmitter and receiver, height of
transmitting antenna, height of receiving antenna, weather conditions, interference sources in the
area, and terrain between receiver and transmitter, including indoor and outdoor structures such as
walls, trees, buildings, hills, and mountains.
Specification XBee-PRO XSC (S3* hardware)
XBee-PRO XSC (S3B hardware)
Indoor/urban range
Up to 370 m (1200 ft)
Up to 610 m (2000 ft)
Outdoor line-of-sight range Up to 9.6 km (6 mi) with dipole
antenna
Up to 24 km (15 mi) with high-
gain antenna
Up to 14 km (9 mi) with dipole
antenna
Up to 45 km (28 mi) with high-
gain antenna
Interface data rate
125 - 65,000 b/s (software selectable, includes non-standard baud
rates)
Throughput data rate
9,600 b/s
9.6 kb/s or 19.2 kb/s
RF data rate
10 kb/s
10 kb/s or 20 kb/s
Transmit power output
+20 dBm (100 mW)
Up to 24 dBm (250 mW) software
selectable
Receiver sensitivity
-106 dBm
-109 dBm at 9600 baud
-107 dBm at 19200 baud
*
The S3 hardware variant is a legacy design that is obsolete. New and old designs should use the
S3B hardware variant.
Power requirements
This table describes the power requirements for the devices.
Specification
XBee-PRO XSC (S3*
hardware)
XBee-PRO XSC (S3B
hardware)
Supply voltage 3.0-3.6 VDC regulated 2.1 to 3.6 VDC
Receive current 65 mA 26 mA typical
Transmit current 265 mA 215 mA at 24 dBm
Power down current 50 uA 2.5 µA typical @3.3 v
*
The S3 hardware variant is a legacy design that is obsolete. New and old designs should use the
S3B hardware variant.
