Frame descriptions Explicit Rx Indicator frame - 0x91

XBee®-PRO 900HP/XSC RF Modules

150

If a device sends the transmission:

n With source and destination endpoints of 0xE0

n Cluster ID = 0x2211

n Profile ID = 0xC105

If AO = 1 on the receiving device, it sends the following frame out its serial interface.

Frame data fields Offset Example

Start delimiter 0 0x7E

Length MSB 1 0x00

LSB 2 0x18

Frame type 3 0x91

64-bit source address MSB 4 0x00

5 0x13

6 0xA2

7 0x00

8 0x40

9 0x52

10 0x2B

LSB 11 0xAA

Reserved

0xFF

0xFE

Source endpoint 14 0xE0

Destination endpoint 15 0xE0

Cluster ID 16 0x22

17 0x11

Profile ID 18 0xC1

19 0x05

Receive options 20 0x02

Default Chapter4
