Frame descriptions Node Identification Indicator frame - 0x95
XBee®-PRO 900HP/XSC RF Modules
155
Frame data
fields Offset Description
Digi
Manufacturer
ID
33-34 Set to the Digi Manufacturer ID.
Digi DD value
(optional)
35-38
Reports the DD value of the responding device. Use the NO command to
enable this field.
RSSI
(optional)
39 Received signal strength indicator. Use the NO command to enable this
field.
Example
If you press the commissioning pushbutton on a remote router with the following settings, this
example would be received:
n 64-bit address of 0x0013A200 407402AC
n Default NI String (0x20)
n NO command enabling the optional RSSI
Frame data fields Offset Example
Start delimiter 0 0x7E
Length
MSB 1 0x00
LSB 2 0x25
Frame type 3 0x95
64-bit source address MSB 4 0x00
5 0x13
6 0xA2
7 0x00
8 0x40
9 0x74
10 0x02
LSB 11 0xAC
Reserved
12
0xFF
13
0xFE
Receive options 14 0xC2
