Frame descriptions Remote Command Response frame - 0x97

XBee®-PRO 900HP/XSC RF Modules

158

Frame data fields Offset Example

Start delimiter 0 0x7E

Length MSB 1 0x00

LSB 2 0x13

Frame type 3 0x97

Frame ID 4 0x55

64-bit source (remote) address MSB 5 0x00

6 0x13

7 0xA2

8 0x00

9 0x40

10 0x52

11 0x2B

LSB 12 0xAA

Reserved

0xFF

14 0xFE

AT commands 15 0x53 (S)

16 0x4C (L)

Command status 17 0x00

Command data 18 0x40

19 0x52

20 0x2B

21 0xAA

Checksum 22 0xF4
