Digitronic Digital Cam Switch Unit
Automationsanlagen GmbH CamCon DC50/51
7.5. Unit configuration
At the first activation of the CamCon, you should initiate a
complete deletion and, if desired, allocate the user keys
for associates. To do this, select the main menu point
"Unit configuration". The display changes to display the
configuration menu:
7.5.1. User key allocation
You can assign different user keys to your associates, each with different access rights.
Attention: As long as no key is created, you can enter every menu with the key code
"5693". When you create your first key, this master key is automatically
deleted. If you forget to create at least one key that allows access to the
configuration menu, you have locked yourself out of the configuration menu
as soon as you leave it. This can be overcome by sending the unit back to
Digitronic or with the entry of a special supervisor number. You can aquire this number
with a phonecall to Digitronic Automationsanlagen.
7.5.1.1. Creating a new user key
Follow these steps to create a new user key:
1. Select the menu point "Key allocation" in the
configuration menu; the display changes to the key
allocation menu:
2. Press the key, and the input field for the name
is underlayed in black.
3. Enter a name. See chapter "5.8. Text input" on page
27.
4. End the text input with the key, and the cursor
moves to the input field "Key number".
5. Enter the key code with the numeric keys (up to 5
numbers).
6. Press the key. The cursor moves to the input
field for the access to the program selection.
7. Choose between "yes" and "no" with keys and
.
8. Press the key. The cursor moves to the input
field for the access to the cam programming.
9. Choose between "yes" and "no" with keys and .
10.Press the key. The cursor moves to the input field for the access to the system menu
11.Choose between "yes" and "no" with keys and .
12.Press the key. The cursor moves to the input field for the access to the configuration menu.
,Version from: Aug. 04 Page: 66
