UC2000 User Manual
24
Copyright @ 2011-2015 Dinstar
Belong To
Parameter
Explanation
Profile
Name
The name of the corresponding SIP profile
Listening Address
The current listening address and the port of SIP
State
Green color means normal running, while red color means
listening address and port of SIP is unavailable.
There are two states :Running and Down
SIP Trunk
Name
The name of the corresponding SIP trunk
Address
The address and the port of peer device under the SIP trunk
Reg
Whether the SIP trunk is registered to the peer device
Transport
Transmission protocol
Heartbeat
If heartbeat is enabled, option message will be sent to peer
device (the peer device is reachable)
Status
Green color means available, while red color means
abnormal, unavailable or prohibited.
There are five statuses: Running, Reged/Up, Noreg/Up,
Trying-Down, Fail-Wait
Profile
The profile that is used by the SIP trunk
SIP Extension
Name
The name of the SIP extension
Extension
The extension number
Status
SIP extension is registered or not.
There are two statuses: Registered. Unregistered
Profile
The profile that is used by the SIP extension
4.3.3 PSTN
Click Status  PSTN, and the following interface will be displayed. On the top is the front view of
UC2000, followed by the real-time information of FXS userboard, FXO userboard, GSM userboard and
CDMA userboard. Green color means available or registered, while red color means abnormal,
unregistered or prohibited.
