UC2000 User Manual
3
Copyright @ 2011-2015 Dinstar
Number
Name
Description
1
Board Number
Board number: from 0 to11 (displayed on the left)
2
Indicators of
FXS/FXO
Port（0,1）
There are two FXS/FXO ports for each FXS/FXO board; the No.0 port is on the
left, while the No.1 port is on the right.
On green
The FXS/FXO port is in off-hook state.
Flash slowly
The FXS/FXO port is in on-hook state.
On dull
Exception occurs on the FXS/FXO port.
3
Board Type
There are four types of board, including FXS, FXO, GSM and CDMA.
4
Screw
The screw is used to fix or unplug a board
5
FXS Port
Port to connect UC2000 with analog phones（RJ11)
6
FXO Port
Port to connect Telco fixed line or connect to the FXS port
7
Slot for GSM
SIM Card
Slot where GSM SIM card is inserted
8
SIM Card
Indicator
Flash slowly
SIM card has been inserted and usable
On dull
SIM card is not inserted or SIM card is unavailable
9
Slot for CDMA
SIM Card
Slot where CDMA SIM card is inserted
10
Antenna Port
Used to connect UC2000 with the antenna for enhancing wireless signal
11
Power Switch
ON
Turn on power
OFF
Turn off power
12
Power Interface
Used to input 100-240VAC
13
Device
Information
The Mac address and S/N of the UC2000
14
Ethernet Port
Ethernet ports, including FE0 and FE1. IP addresses of both are 192.168.11.1 by
default.
15
Screw for
Master Control
Board
Used to fix or unplug the master control board
16
Master Control
Board
The core of UC2000
17
Console Port
RS232 standard; Baud Rate: 115200bps
18
RUN
On green
UC2000 is booting up
On dull
UC2000 has malfunctioned
Flash fast
(Flash every 0.5s)
UC2000 is running normally
19
Grounding Port
Used for ground connection
