Cooling System Specifications Coding System
Page 7-22 DODGE Turbo Diesel
Cooling System Specifications
Coolant Capacity (Engine Only) -
liter
[U.S. quarts] 10.5
[11.1]
Standard
Modulating
Thermostat - Range
0
C [°F]
Maximum
Start 83 [181]
Maximum
Fully Open 95 [203]
Pressure
Cap kPa [PSI] 110°C [23Q°F] Systems 103 [15]
Cooling System Capacity
Engine
Model
Drive Radiator Capacity
Liter
Width
(Inches) U.S. Quarts-Liter
5.9 Liter Diesel
D250,350
2-Wheel
(Automatic) 30.19 15.7
[16.5]
5.9 Liter Diesei
D250,350
2-Wheei
(Manual)
30.19 14.7
[15.5]
5.9 Liter Diesel
W250,350
4-Wheei
(Automatic) 30.19 15.7
[16.5]
5.9 Liter Diesei
W250,350
4-Wheei
(Manual)
30.19 14.7
[15.5]
Component Capscrew Torque Values
N-m Inch N-m Foot
Pounds Pounds
Water
Pump C/S - - 24 N-m [18 ft-lbs]
Viscous
Fan Drive Attaching Nut - - 57 N-m [42 ft-lbs]
Fan
Attaching C/S (to
Viscous
Fan Drive) ...... - - 20 N-m [15 ft-lbs]
Fan
Pulley C/S - -- 9 N-m [7 ft-lbs]
Fan
Hub C/S - - 24 N-m [18 ft-lbs]
Alternator Link C/S - -- 24 N-m
[18ft-ibs]
Alternator
Mounting
Bolt - - 43 N-m [32 ft-lbs]
Fan
Hub Shaft C/S - -- 77 N-m [57 ft-lbs]
Thermostat Housing C/S - - 24 N-m [18 ft-lbs]
Shroud
Mounting
Nuts 11 N-m [95 in-lbs] - -
Radiator
Mounting
Nuts 11 N-m [95 in-lbs]
Drain Cock 17 N-m [150 in-lbs]
Drain Cock Handle 2-4 N-m
[18-35
in-lbs] - -
Oil Coder Fittings-
Lines
to Connector (Trans. End) and
Engine MTG Cooler 54 N-m [40 ft-lbs]
Trans.
Cooler Hose Clamps 2 N-m [18 in-lbs]
Radiator Hose Clamp 4 N-m [35 in-lbs]
