Doosan DISD SD 310 - Torque Limits for Screws

TORQUE LIMITS FOR SCREWS (IN Nm) ACCORDING TO ZF-STANPARDS 148
Coefficient of friction: μ total = 0,12 for screws and nuts without after treatments as well as for phosphates nuts. Tighten by
hand!
Torque limits, of not exspecially, can be taken from the following list:
Metric ISO-Standard Thread DIN 13, Page 13
Size
8.8
10.9
12.9
M4
2.8
4.1
4.8
M5
5.5
8.1
9.5
M6
9.5
14
16.5
M7
15.5
23
27
M8
23
34
40
M10
46
68
79
M12
79
117
135
M14
125
185
215
M16
195
280
330
M18
280
390
460
M20
390
560
650
M22
530
750
880
M24
670
960
1120
M27
1000
1400
1650
M30
1350
1900
2250
M33
1850
2600
3000
M36
2350
3300
3900
M39
3000
4300
5100
Metric ISO-Fine Tread DIN 13, Page 13
Abmessung
8.8
10.9
12.9
M8X1
24.6
36
43
M9X1
36
53
62
M10X1
52
76
89
M10X1.25
49
72
84
M12X1.25
87
125
150
M12X1.5
83
122
145
M14X1.5
135
200
235
M16X1.5
205
300
360
M18X1.5
310
440
520
M18X2
290
420
490
M20X1.5
430
620
720
M22X1.5
580
820
960
M24X1.5
760
1090
1270
M24X2
730
1040
1220
M27X1.5
1110
1580
1850
M27X2
1070
1500
1800
M30X1.5
1540
2190
2560
M30X2
1490
2120
2480
M33X1.5
2050
2920
3420
M33X2
2000
2800
3300
M36X1.5
2680
3820
4470
M36X3
32002500
3500
4100
M39X1.5
3430
4890
5720
M39X3
3200
4600
5300
