Assembly parts assembling
Install hub assembly
1. Keep the large end of hub upward, assemble
bearing outer ring .
2 turn over to keep the small end of hub upward and
assemble bearing outer ring.
3. Bearing inner ring assembled.
4. Check completeness of oil seal. Coat lubrication oil in
oil seal seat evenly, and assemble oil seal in oil seal seat.
Front Axle SPC000009
Page 33
