Doosan DISD SD 310 - Parts List

PARTS LIST
Reference Number
Description
Reference Number
Description
1
REDUCER ASSY,WHEEL
11
REDUCER ASSY,MAIN
2
HOUSING ASSY, AXLE
12
16 WASHER, SPRING
3
BREATHER
13
M16×1.5×40-8.8 BOLT
4
BRAKE UNIT
14
WASHER,SEAL
5
20 WASHER, SPRING
15
6
M20×1.5×55-10.9 BOLT
16
7
PLUG,MAGNETIC
17
8
PLETE,NAME
18
9
RIVET
10
D10×30 PIN
SPC000010 Rear Axle
Page 4
Figure 2
