Doosan DISD SD 310 - Parts List

PARTS LIST
Reference Number
Description
Reference Number
Description
1
REDUCER ASSY,WHEEL
11
PLUG,MAGNETIC
2
HOUSING ASSY, AXLE
12
D1030 PIN
3
COVER ASSY
130
REDUCER ASSY,MAIN
4
8 WASHER,PLAIN
14
16 WASHER, SPRING
5
8 WASHER, SPRING
15
M161.540-8.8 BOLT
6
M820-8.8 BOLT
16
PLETE,NAME
7
BREATHER
17
RIVET
8
BRAKE UNIT
18
WASHER,SEAL
9
20 WASHER, SPRING
10
M201.555-10.9 BOLT
SPC000009 Front Axle
Page 4
Figure 2
