Doosan DISD SD 310 - Gearbox

1.2 ALUMINIUM SAND-CASTING
GEARBOX CONTROL
1.2.1 Version : With 4 Solenoid valves
and attached 2-stage pressure control
valve !
1.2.1.1 DISASSEMBLY
Remove delivery line.
( S ) Adjusting screws (M8) 5870 204
011
Relax spring clip and remove cover.
Pull oil cable shoes and remove cable harness.
Loosen socket head screws and remove solenoid
valves.
Remove components, see Figure on the right !
SPC000007 Transmission and Torque Converter
Page 26
Figure 36
Figure 37
Figure 38
Figure 35
