Loosen two socket head screws and fix shiftcontrol
housing provisionally, using a Special Tool ( S ).
Now, loosen the remaining socket head screws and
separate shift-control housing (is spring-loaded)
from the valve body by uniform loosening of the nuts
( S ).
( S ) Adjusting screws (M5) 5870 204 036
with nut
( S ) Adjusting screws (M6) 5870 204 049
with nut
Dismantle pressure control valve.
Remove components.
Remove stop plates (Arrows) and demount detent
blocks (2x).
Transmission and Torque Converter SPC000007
Page 27
Figure 39
Figure 41
Figure 42
Figure 40
