Doosan DISD SD 310 - Pneumatic Brake Valve

3. Pneumatic brake valve
Reference
Number
Description
Reference
Number
Description
1
MANDRIL
7
VALVE BODY
2
PEDAL ASS’Y
8
INTAKE VALVE ASS’Y
3
ANTIDUST COVER
9
VALVE ASS’Y
4
BALANCING SPRING
10
OUTLET VALVE ASS’Y
5
PISTON ASS’Y
11
SEALING FIN
6
PISTON FOUR SPRING
12
SPRING SEAT
Brake System SPC000021
Page 7
Figure 4
