Doosan DISD SD 310 - Booster Pump; Special Tools and Materials

4. Booster pump
Reference
Number
Description
Reference
Number
Description
1
STRENGTH CYLINDER
8
PISTON
2
Y-SEAL RING
9
BREAKING PUMP
3
PISTON
10
AIR OUTLET SCREW
4
RELEASING SPRING
11
PUSHING BORER
5
ENDPLATE
12
MAIN PUMP FUR BOWL
6
STORAGE CUP
13
X-SEAL RING
7
PUTTING SEAT
SPECIAL TOOLS AND MATERIALS
LUBRICANTS, SEALANTS AND OIL
SPC000021 Brake System
Page 8
Figure 5
