Doosan DISD SD 310 - Monitoring System

Monitoring System
Monitoring system of the equipment includes all kinds of oil pressure gauges, oil pressure sensor plug,
water temperature gauge, water temperature sensor plug, voltmeter, barometer and low pressure warning
device, etc.
Reference Number
Description
Reference Number
Description
1
Gauge Panel
6
Fuel Sensor
2
Battery
7
Sensor
3
Alternator
8
Temperature Sensor
4
Rocker Switch
9
Back Buzzer Switch
5
Switchgroup
Monitoring system will process information collected from all sensors, the instrument panel will indicate
all data and warning signals.
SPC000025 Electrical System
Page 14
2
8
1
3
4
5
6
7
9
Figure 6. Monitoring system
