OVERVIEW
Voltage of electrical system of the machine is DC 24V, the rated voltage of all electrical parts is 24V.
Electrical cable wire adopts single wire system, and negative earth is adopted. Electrical system includes two
serial 12V storage batteries and three phase DC generator with entire rectifier. Wire harness of the system
can be distinguished by different insulation colour. Each colour symbol used for electrical system is listed
below.
Electric Wire Color
Symbol
Color
Symbol
Color
W
White
R
Red
G
Green
Gr
Gray
Or
Orange
P
Pink
B
Black
Y
Yellow
L
Blue
Br
Brown
Lg
Light Green
V
Violet
NOTE: RW: Red wire with White stripe.
R - Base Color, W - Stripe Color.
NOTE: 0.85G: Nominal sectional area of wire core less insulator = 0.85 mm2 (0.03 in2).
