Optional versions and additional equipment
for the transmissions of the WG range
1 Converter housing for direct
installation
2 Torque converter
3 Lock-up clutch
4 Cover for separate installation
5 Retarder
6 HN 500 converter transmission
7 Input flange (for separate
installation)
8 Centre distance input/ output
shafts
9 Axle disconnect unit
10 Parking brake
11 Speedometer connection
12 Inter-axle differential
13 Axle drive, flange-mounted
14 Multi-disc clutch for 4.5 and 6-
speed version
15 Emergency steering pump
16 PTO unit, engine driven
17 Transmission control
18 Steering column switch SG 4/S G
6
19 Console switch SG 4/SG 6
20 Rotary reversing switch DW 1
21 Automatic control unite EST 2
22 Inching valve
23 Dual pressure control valve
24 Pressure cut-out
25 Micro-filter
26 Transmission connection for
separate filter installation
27 Converter charge and shift pu
mp
SPC000007 Transmission and Torque Converter
Page 10
