3.1.5 REMOVE MULTI-DISK CLUTCHES
NOTE;
In case of Versions with Spur Rear fixing K1, the
two set screws (Arrows) have to be removed prior to
the disassembly of the axle, see Figure on the right!
Loosen hex. nuts and pull axle by means of Special
device out of the clutch, resp. gear case.
(S) Puller 5870 000 069
Lift clutch out of the gear case and deposit it.
NOTE:
Use lifting device!
Remove clutch KR/K2 accordingly.
In the case of clutch K4/K3, push the lower spacing
washer to the rear. Only then, the clutch can be
removed.
(S) Lifting device 5870 350 041
3.1.6 REMOVE COUNTERSHAFT
ASSEMBLY
Remove closing cover.
SPC000007 Transmission and Torque Converter
Page 96
