Fasten output flange by means of disk and hex.
head screws.
NOTE :
Wet contact area of the disk and the screw heads
with sealing compound !
Torque limit (M8/10.9) 34 Nm
Fix hex. head screws by means of lock plate.
( S ) Driver 5870 057 011
( S ) Handle 5870 260 002
Install disk and assemble driving bush.
NOTE :
Pay attention to the installation position of the
driving bush, see Figure !
Fix driving bush free of play by means of shim(s)
and circlip.
SPC000007 Transmission and Torque Converter
Page 188
