Doosan DISD SD 310 - Page 428

Loosen closing cover by central tapping and remove
it.
Loosen hex. head screws and remove them along
with flat washers (Figure 44).
Now, take cover plate out of the gear case (Figure
45).
Loosen socket head screws and remove supporting
tube.
NOTE ;
Socket head screws are secured with Loctite !
( S ) Allen screw A/F-8 5870 290 001
SPC000007 Transmission and Torque Converter
Page 200
Figure 43
Figure 44
Figure 45
Figure 46
