Doosan DISD SD 310 - Page 513

4. Loosened bolt of oil seal seat ,Take out oil seal
seat and asbestos gasket.
5. Take out bearing.
Dismantle main drive assembly
1. Put main drive assembly (input flange upward)
horizontally and fixed on supporting.
2. Dismantle thrust bolts.
Rear Axle SPC000010
Page 19
Figure 31
Figure 32
Figure 33
Figure 34
