4. Screw down piston bolts with special tools (refer
to figure 12).
5Put piston rod in cylinder barrel (refer to figure
13).
6. Screw down bolts of cylinder cover and cylinder
barrel (refer to figure 14).
SPC000011 Cylinder
Page 8
Figure 12
Figure 13
Figure 14
