Doosan DISD SD 310 - Page 612

PARTS LIST
Figure 2
SPC000018 Motor
Page 4
Reference Number
Description
Reference Number
Description
1
Valve
14
Guarnizione
2
Body
15
Shaft Seal BA
3
Front Cover
16
Shaft Seal G
4
Rear Cover
17
Ring 30
5
Thrust Plate
18
Ring 20
6
Drive Gear
19
Antiextrusion
7
Driven Gear
20
Key
8
Ball Bearing
21
Flange
9
Nut
22
HUB
10
Washer B14
23
Back-up Washer
11
Washer 10
24
Support Shaft
12
Seal PL20
25
Dowel Pin
13
Standard Seal PL20
26
Screw
