Reference Number
Description
Reference Number
Description
1
Disconnect Switch
6
Starter Switch
2
Battery
7
Fuse
3
Starter
8
Battery Relay
4
Starter Relay
9
Alternator
5
Diode
10
Saftey Start Relay
Electrical System SPC000025
Page 5
Figure 1. Power supply circuit diagram
