Issued June 2020
Operation
Copyright 2020, Heil Environmental
Printed in U.S.A.
94
SETTING UP AN EJECT UNIT FOR UNLOADING
Set up the Unit
After positioning unit on firm stable ground for unloading at
the landfill, set up as follows.
WARNING
Make sure that all individuals are clear of the point of
operation before actuating controls. Be ready to stop or
reverse the function.
1. Shift the transmission to NEUTRAL.
2. APPLY the parking brake and MAKE SURE it is
holding.
3. PRESS and RELEASE the pump (red) button on the
Joystick to activate the Pump.
4. UNLOCK the tailgate by PUSHING and HOLDING the
T/G UNLOCK button on the Main Push Button
Controls (located on control panel in cab), until the
tailgate is completely unlocked.
Raise the Tailgate
DANGER
A tailgate in motion is dangerous. Serious injury or death
may occur if a person is struck by a moving tailgate or
becomes trapped between the tailgate and the body. Clear
the area near the tailgate of all unnecessary people before
you lower the tailgate.
Raise the Tailgate (Continued)
1. PRESS and HOLD the T/G RAISE button until the
tailgate is COMPLETELY raised, which is about
30º above the body. See the figure below.
2. RELEASE the switch.
The BODY TAILGATE UP notification turns ON and the
in-cab alarm will sound to indicate the tailgate is open.
Figure 49. Raise the Tailgate
